COMPLETE LIFT PACKAGE

Platform Lift

PLATFORM LIFT CIBES from 250KG to 350KG
Platform Lift Cibes  is an all-inclusive lift concept, which is easy to integrate with new and existing buildings without major construction work.
Description
Platform Lift Cibes  is an all-inclusive lift concept, which is easy to integrate with new and existing buildings without major construction work.

♦ Installation environment:Indoor or outdoor
♦Installation :No foundation pit installation, high 80MM & Foundation pit installation, deep 80MM

♦Top level ≮ 2400MM
♦Stop Station Maximum 5-storey station
♦Maximum 13m
♦Standard level:3.5 m/floor
♦Access directions:180°through /90°/ or original in / out
♦Power:3 KW/AC220V/50HZ(Home)
3KW/AC220V/50HZ (domestic)
♦Driving mode:hydraulic pressure
♦Running speed:80-120 MM/sec
♦Gate control:Automatic or manual (optional)
♦Control method:Click Hold down run / auto
♦Maximum load bearing:250KG/350KG
♦Working temperature:-5C°/ +40C°

Safety Device:
   Manual emergency drop and door opening device
   Platform master panel preferred
   Emergency stop button
   Layer and equipment linkage control
  Anti-fall mechanical device
  Safety net around the platform
  Electronic control system to prevent overcurrent
  Overload protection
  Platform Overweight Protection
 Hydraulic oil circuit explosionproof valve
