| Code | Capacity(KGS) | Speed(m/s) | Power(KW) | Traction Sheave(mm) | Travel Height |
| 41T-W7 | 320 | 1 | 2.5 | Φ325*3*Φ8*12 | ＜=80M |
| 1.5 | 3.7 | ||||
| 1.6 | 4 | ||||
| 1.75 | 4.3 | ||||
| 450 | 1 | 3.3 | Φ325*4*Φ8*12 | ||
| 1.5 | 4.9 | ||||
| 1.6 | 5.3 | ||||
| 1.75 | 5.7 | ||||
| 550 | 0.63 | 2.3 | Φ325*5*Φ8*12 | ||
| 0.75 | 2.7 | ||||
| 1 | 3.6 | ||||
| 630 | 0.63 | 2.5 | |||
| 0.75 | 3 | ||||
| 1 | 4 | ||||
| 41T-W9 | 630 | 1 | 4.2 | Φ400*5*Φ10*16 | ＜=100M |
| 1.5 | 6.3 | ||||
| 1.6 | 6.7 | ||||
| 1.75 | 7.3 | ||||
| 2 | 8.4 | ||||
| 800 | 1 | 5.3 | |||
| 1.5 | 8 | ||||
| 1.6 | 8.5 | ||||
| 1.75 | 9.3 | ||||
| 2 | 10.7 | ||||
| 1000 | 1 | 6.5 | |||
| 1.5 | 9.8 | ||||
| 1.6 | 10.4 | ||||
| 1.75 | 11.4 | ||||
| 2 | 13.1 | ||||
| 1150 | 1 | 7.6 | Φ340*8*Φ8*12 | ||
| 1.5 | 11.4 | ||||
| 1.6 | 12.3 | ||||
| 1.75 | 13.5 | ||||
| 2 | 15.3 |
| Code | Capacity(KGS) | Speed(m/s) | Power(KW) | Traction Sheave(mm) | Travel Height |
| 41T-ERS | 320 | 1 | 2.2 | Φ320*3*Φ8*12 | ＜=80 |
| 1.5 | 3.3 | ||||
| 1.6 | 3.5 | ||||
| 1.75 | 3.8 | ||||
| 450 | 1 | 3 | Φ320*4*Φ8*12 | ||
| 1.5 | 4.5 | ||||
| 1.6 | 4.8 | ||||
| 1.75 | 5.3 | ||||
| 630 | 1 | 4 | Φ240*7*Φ6.5*12 | ＜=80 | |
| 1.5 | 6 | ||||
| 1.6 | 6.4 | ||||
| 1.75 | 7 | ||||
| 41T-ER2D | 800 | 1 | 5.6 | Φ320*3*Φ8*12 | ＜=80 |
| 800 | 1.5 | 8.4 | |||
| 800 | 1.6 | 9 | |||
| 800 | 1.75 | 9.8 | |||
| 1000 | 1 | 6.9 | Φ320*7*Φ8*12 | ||
| 1000 | 1.5 | 10.3 | |||
| 1000 | 1.6 | 11 | |||
| 1000 | 1.75 | 12 | |||
| 41T-ER3D | 1150 | 1 | 7.8 | Φ320*8*Φ8*12 | ＜=80 |
| 1150 | 1.5 | 11.8 | |||
| 1150 | 1.6 | 12.7 | |||
| 1150 | 1.75 | 13.8 | |||
| 1250 | 1 | 8.5 | |||
| 1250 | 1.5 | 12.7 | |||
| 1250 | 1.6 | 13.8 | |||
| 1250 | 1.75 | 14.9 |
